Features and Advantages...
- Completely rust and corrosion free.
- Excellent resistance to impact and abrasion.
- Light weight, easy for transportation and installation.
- Smooth, fiber-free inner surface with wide chemical resistance.
Operation Requirement...
- Operating pressure ≤0.7Mpa
- Operating temperature ≤49°C
- Vacuum ≤127 mmHg (5" Hg)
|
Size
(inch)
|
Size
(mm)
|
Opening
(inch)
|
Capacity
|
Operating Pressure
|
Filtration Velocity
m3/hr
|
|
Top
|
Bottom
|
Gallons
|
Liters
|
MPa
|
Bar
|
|
10 X 54
|
200 X 1350
|
2.5" NPSM
|
-
|
16.4
|
62.0
|
0.7
|
7.0
|
0.6~1.5
|
|
12 X 52
|
300 X 1300
|
2.5" NPSM
|
-
|
22.2
|
84.0
|
0.7
|
7.0
|
1.6~2.2
|
|
13 X 54
|
325 X 1350
|
2.5" NPSM
|
-
|
27.5
|
104.0
|
0.7
|
7.0
|
2.0~2.5
|
|
14 X 65
|
350 X 1625
|
4" NPSM
|
-
|
40.6
|
154.0
|
0.7
|
7.0
|
2.5~3.0
|
|
16 X 65
|
400 X 1625
|
4" NPSM
|
-
|
49.0
|
185.0
|
0.7
|
7.0
|
3.2~4.5
|
|
18 X 65
|
450 X 1625
|
4" NPSM
|
4" NPSM
|
66.7
|
251.8
|
0.7
|
7.0
|
3.5~4.8
|
|
21 x 62
|
525 X 1550
|
4" NPSM
|
4" NPSM
|
88.0
|
333.0
|
0.7
|
7.0
|
4.0~5.5
|
|
24 X 72
|
600 X 1800
|
4" NPSM
|
4" NPSM
|
126.8
|
480.0
|
0.7
|
7.0
|
6.2~8.2
|
|
30 X 72
|
750 X 1800
|
4" NPSM
|
4" NPSM
|
195.5
|
740.0
|
0.7
|
7.0
|
7.2~12.2
|
|
36 X 72
|
900 X 1800
|
4" NPSM
|
4" NPSM
|
283.0
|
1,071.0
|
0.7
|
7.0
|
13.2~16.2
|
|
40 X 72
|
1250 X 1800
|
6" FLG
|
6" FLG
|
338.7
|
1,282.0
|
0.7
|
7.0
|
16.2~22.2
|
|
48 X 72
|
1200 X 1800
|
6" FLG
|
6" FLG
|
477.7
|
1,808.0
|
0.7
|
7.0
|
22~27
|
|
48 X 96
|
1200 X 2400
|
6" FLG
|
6" FLG
|
657.1
|
2,487.0
|
0.7
|
7.0
|
30~40
|
|
56 X 96
|
1400 X 2400
|
6" FLG
|
6" FLG
|
844.1
|
3,195.0
|
0.7
|
7.0
|
36~45
|
|
60 X 96
|
1500 X 2400
|
6" FLG
|
6" FLG
|
958.0
|
3,626.0
|
0.7
|
7.0
|
40~55
|
|
65 X 110
|
1625 X 2750
|
6" FLG
|
6" FLG
|
1,290.1
|
4,883.0
|
0.7
|
7.0
|
60~70
|
|
72 X 110
|
1800 X 2750
|
6" FLG
|
6" FLG
|
1,681.4
|
6,364.0
|
0.7
|
7.0
|
70~80
|
|
80 X 126
|
2000 X 3150
|
6" FLG
|
6" FLG
|
2,404.0
|
10,773.0
|
0.7
|
7.0
|
80~90
|
|
89 X 126
|
2225 X 3150
|
6" FLG
|
6" FLG
|
2,846.2
|
10,773.0
|
0.7
|
7.0
|
90~100
|
|
